A wide range of rack accessories

A wide range of rack accessories

Thanks to a wide range of rack accessories, you can customize your storage system exactly the way you want. Of course, our accessories are of the highest quality and can be configured on fixed and mobile storage systems with manual and electric drives. Please contact us!

Storage drawers LED lighting Pull-out shelf Sliding book support
Compartment clamp Full height divider

Label holder
A4, A5, A6

Rod dividers
Rear / Front
shelf stopper
Pull-out frame L’Obique / TUB frame Clothes rail

LED rack lighting

LED rack lighting

LED aisle lights turn on automatically when the aisle is open. In a Dynamic II system (mobile racks with electric drive), the lights turn off automatically after a certain amount of time.

LED lighting has the important feature of having low levels of UV and infrared radiation. This makes LED lighting extremely suitable if sensitive items are stored. It prevents light damage to the items. The lack of UV radiation also has the property that the lighting will hardly fade or yellow (fluorescent lighting will yellow quickly). In addition, due to the lack of infrared radiation, LED lighting emits little heat, is much more energy efficient than traditional lighting, and has a very long life (over 35,000 hours of illumination).

The dimensions and number of luminaires for the corridor are based on an average luminous flux of 150 LUX measured at a distance of 1 meter from floor level.

It is also possible to use inter-rack LED lighting in mobile shelving with manual (crank) drive.



Aluminium boxes

Aluminium boxes

We offer you a wide range of practical aluminium boxes for transporting or storing various types of goods. These boxes are used in industry, warehouses, offices, archives, construction sites and even at home. With over a dozen product types, every customer will find the right solution for them.

The boxes we offer are:

  • lightweight,
  • stable,
  • dimensional,
  • durable and reusable,
  • resistant to corrosion and weather conditions.

These features are a guarantee of quality. For more information, please contact us through the contact form or directly by email at This email address is being protected from spambots. You need JavaScript enabled to view it.



Safety Master

Safety Master

The new standard in safety

In November 2020, we introduced a new solution that guarantees the complete safety of the COMPACTUS DYNAMIC II electric rack system. Designed for full protection. Multiple systems in one elegant unit that keeps users and products safe. We consider this to be a must for all electronically controlled systems. The safety level of our Compactus® series has never been so high.

Entry detection

The passive infrared (PIR) technology in our modern system detects a person entering an open passage. The combination of the camera with our LED inter-rack lighting system ensures that the open corridor is used as long as the lights are on. Detection of entry allows the system to know if someone will enter a closing corridor and stop the movement of the system, further increasing the safety of users.

Person or object detection

The automatic slide safety system takes a picture of the open and empty passage. Whenever someone wants to close a doorway, the system compares the actual situation with the saved image of an empty doorway. If people or objects (larger than A5 or 300 cm2) are detected in the doorway, the door will not be closed and it will return to the passive safety procedure (system movement is stopped and the "eye" icon is displayed on both sides of the door. The user must press both " eyes ", one by one while looking at the open passage. This visual safety ensures that the user looks into the passage and makes sure that he can pass the mobile rack)

GDPR compliant

Our automatic slide safety system is GDPR compliant, only storing an image of an empty transition. The processing of images of the empty transition and the current situation between the rack is done directly in the camera, at the moment, it is not possible to download or export the image.

Additionally, we invite you to watch the video showing the work of the new security system: <click here>



Step into the future

Step into the future

Automated storage technology goes even higher

Sliding racks have evolved over the years, changing their design elements and drive. Initially, they were moved using a special handle or crank using the strength of human muscles to move. Currently, Międzynarodowe Centrum Budownictwa Sp. z o.o. recommends electric drive and microprocessor controlled mobile racks.

With electric drive

Mobile racks MCB Sp. z o.o. they run on rails embedded in the floor or paved with their own floor filling the space between the shelves. Above the rails there is a chassis, equipped with road wheels and a single-phase 24 V DC electric motor (so-called safe) with an appropriately selected gear. The power of the electric motor is 50 W. The multi-speed gearbox located behind the motor ensures long life and high efficiency. The high quality and durable construction is adapted to carrying heavy loads, up to 15 tons per one row of mobile racks. The chassis has advanced safety systems, among others. photocells (when the laser beam is cut, the racks stop), a distance sensor (responsible for maintaining the set distance between the racks) and MCMS - load control system for the drive system (allows you to react to overloads of the motor driving the rack in the event of encountering an obstacle while driving and is one of the elements of the passive safety system). The racks, regardless of the transferred load, begin and end their movement with a constant acceleration, and they travel the work space at a constant speed, regardless of the load. On the mobile bases, there are shelves of various designs tailored to the requirements of users. The racks can have full or openwork Sysco or Compact walls made of powder coated steel. For particularly loaded racks, we offer walls made in the HI280 openwork technology - rack elements made of galvanized steel sheet. The racks can be equipped with: shelves, drawers, shelf dividers, slats supporting the contents, pull-out frames, support beams, etc. On the front wall of the rack there is a control panel with a Dynamic II touch screen.

Microprocessor control Dynamic II

DYNAMIC II is a modern operating system that controls and controls the movement of racks moving at a constant speed regardless of their load. Thanks to the use of the "soft start and stop" function, vibrations and the influence of inertia on the stored objects, which remain in their place during them, are eliminated. The operating panel can be controlled and controlled by manual control from the touch screen or remotely from a smartphone or tablet. Remote control is carried out using a Wi-Fi signal generated by the desktop. No internet connection or SIM card required.

The local Wi-Fi network generated by Dynamic II enables the control system to cooperate with other intelligent warehouse systems such as fire protection, lighting, ventilation and air conditioning systems. In addition, the mobile functions of the Dynamic II system enable remote diagnostics and control of correct operation, including the transmission of information about errors in the system operation. The operation is simple and completely safe for the user. The system supports the following languages: Polish, English, Dutch, German, Danish, Italian and French. The control panel also allows you to control access to individual shelves. The use of the device may be limited by an electronic PIN code or a magnetic RFID card. A different PIN code and a different RFID card can be allocated separately for each row of racks or for any number of them. Mobile functions allow you to control who is using a given rack and when.

Automatic security system

The control system is equipped with a unique "Automatic Safety System". This function fully protects the operator, the stored materials and the racks themselves from damage in the event that a person or stored items are found in the space between the racks during the rack movement. When we initiate the rack movement process, the system automatically controls the space between the racks using an image recognition program. When we want to close the door, the system compares the actual state with the image recorded immediately after sliding the racks apart. If people, objects or elements protruding beyond the outline of the racks are detected in the space between the racks, the passage will not be closed.

Multi-level mobile racks

The Double Decker multi-level shelving system is an extension of the Compactus sliding rack system with electric drive and Dynamic II control for high rooms. These are multi-level mobile racks, and at the same time an ideal design and technological solution in high rooms above 4.5 m. Double Decker provides a fourfold increase in storage capacity compared to stationary racks, while being extremely simple and safe to use. Double Decker sliding racks is a two-level racking system with its own mezzanine, based on the side walls of the lower level of mobile racks. This solution allows for more effective use of high rooms, and the own mezzanine enables the operation of high racks without the use of additional ladders, trolleys, specialized means of transport, etc. The mezzanine can be made as a full floor or a Vema grating. The Double Decker construction uses and uses all the elements and benefits of Dynamic II mobile racks. In addition, multi-level mobile racks allow you to resign from the need to divide high rooms with ceilings into smaller volumes. This solution does not require a building permit. It eliminates the cost of constructing a ceiling and reduces the costs of ventilation, air conditioning, heating, fire protection systems and lighting. The construction of a single-storey building, as compared to a multi-storey building, requires significantly less financial outlays, and construction and installation works last shorter. In the case of multi-storey buildings, it is necessary to duplicate the installation at each level, which entails a multiplied cost of both construction and operation. The mezzanine area is not counted when determining the base of the annual real estate tax, as opposed to the area of ​​separate floors. Double Decker sliding racks with an electric drive have an implemented Dynamic II microprocessor control system. In one system of racks offered by Międzynarodowe Centrum Budownictwa Sp. z o.o. you can combine multiple functions to create a centralized storage unit tailored to your individual needs. We enter the future with the Double Decker system.



New solutions for warehouses

New solutions for warehouses

We are expanding our offer with a new solution for warehouses that combine the design and functionality of electric drive systems and highly durable warehouse racks.

Electrically powered sliding racks are a dynamic solution that can double the load capacity of the warehouse within the existing space compared to standard pallet racks.

The combination of electric rack chassis and sides and beams / shelves of pallet racks allows for the storage of pallets, optimizing the cost and storage space.

Technical parameters of the racks:

Height [mm] Lenght [mm] Depth [mm] Load capacities
From 1750 to 4500
in multiples of 250
1000 400 Up to 1500 kg/level
1250 500 Up to 4500 kg/bay uniformly distributed and depending on configuration
  1500 600
  1800 700
  2000 800
  2250 900
  2500 1000
  2700 1100
  3000 1200

Moreover, this system offers all the amenities and functions implemented in the Dynamic II control system.

With multiple work opportunities, safety messages and updates easily accessible via the Dynamic II mobile apps, these systems are the future of microprocessor controlled electrical shelving.

Control your storage system by turning the handle or touching the touchscreen.

✔ Intelligent user interface
✔ Built-in RF-ID reader
✔ Built-in proximity sensor

Configure system functions and settings using the Dynamic II application.

✔ Users and groups
✔ Access control
✔ Naming of corridors
✔ LED lighting

Take care of the safety of users and the security of storage.

✔ Overload sensor (MCMS)
✔ Stop button - safety
✔ Photocells
✔ Passive safety
✔ Protection against burglary
✔ Security cameras



Protection of cultural heritage in Ukraine

Protection of cultural heritage in Ukraine

The state of emergency in Ukraine requires solidarity and support from us.

As part of the help in the evacuation of collections from areas endangered by war, we have delivered mobile and stationary racks to warehouses in our eastern neighbor to:

  • The National Museum in Lviv named after Andrzej Szeptycki
  • Memorial Museum of Totalitarian Regimes
  • Lviv National Scientific Library of Ukraine Vasyl Stefanyk

This is to protect monuments and cultural heritage in Ukraine.



Intelligent security system

Intelligent security system

Thanks to the latest Dynamic II control system, there are many options for securing stored files or secret files. The multifunctionality of the control panel makes it very flexible. For many of our clients, on special request, the racks have been secured with RFID cards. Dynamic II allows you to program access cards with a different frequency range. Their wide range of compatibility creates unlimited possibilities, which means that one card can be used for many units.



Electric rollers

Electric rollers

The rollers are driven by an electric motor. The average speed of descent and entry of the fights is 5 cm / s. They run on specially profiled treadmills that are adjusted to the storage height (up to 4 meters).

As standard, they are powder coated with epoxy paint in RAL9002 color. Painting takes place after all holes and technological bends are made. In order to provide better anti-corrosion protection, the steel sheet is protected with a phosphate coating with a thickness of min 500 mg / m2.

They are controlled by a special remote control.

To see more photos, click <here>




Visual safety

Visual safety

The new standard in safety

In November 2020, we introduced a new solution that guarantees the full security of the electric drive racking system. The cameras are ideal for museums, archives, warehouses, etc. with increased safety standards for stored facilities.

Entry detection

The passive infrared (PIR) technology in our modern system detects a person entering an open passage. The combination of the camera with our LED inter-rack lighting system ensures that the open corridor is used as long as the lights are on. Detection of entry allows the system to know if someone will enter a closing corridor and stop the movement of the system, further increasing the safety of users.

Person or object detection

The automatic slide safety system takes a picture of the open and empty passage. Whenever someone wants to close a doorway, the system compares the actual situation with the saved image of an empty doorway. If people or objects (larger than A5 or 300 cm2) are detected in the doorway, the door will not be closed and it will return to the passive safety procedure (system movement is stopped and the "eye" icon is displayed on both sides of the door. The user must press both " eyes ", one by one while looking at the open passage. This visual safety ensures that the user looks into the passage and makes sure that he can pass the mobile rack)

GDPR compliant

Our automatic slide safety system is GDPR compliant, only storing an image of an empty transition. The processing of images of the empty transition and the current situation between the rack is done directly in the camera, at the moment, it is not possible to download or export the image.

Additionally, we invite you to watch the video showing the work of the new security system: <click here>
